Using React Redux Connect with TypeScript

When using Redux in a TypeScript React Application, we will run into some snags. One of the main ones is correctly typing Components using connect. We want to get type inference whenever possible to reduce human error when using typescript. Fortunately there is an easy a way to use Redux's connect with type inference in our TSX projects by leveraging the Dispatch, and ConnectedProps types. You will be able to get types straight from your mapStateToProps and mapDispatchToProps into any React Class Component or React Functional Component.

Typing your Component with ConnectedProps

To use connect and get type inference State, Selectors, and Actions must be typed already. They can all be set up to get automatic type inference with the correct setup. If this is not done yet, go to Redux Type Setup

We will be working with a theoretical Header Component that gets user information from Redux.

The full guide starts after the resulting code.

TLDR: Resulting Code

import React, { Dispatch } from 'react';
import { connect, ConnectedProps } from 'react-redux';
import { selectCurrentUser } from '../../redux/user/user.selectors';
import { signOutStart } from '../../redux/user/user.actions';

//Our Type Imports
import { State } from '../../redux/root-reducer.types';
import { UserActions } from '../../redux/user/user.types';

const Header: React.FC<HeaderProps> = ({
	currentUser,
	signOutStart,
}) => (
	... //Component Code
)

const mapStateToProps = (state: State) => ({
	currentUser: selectCurrentUser(state),
});

const mapDispatchToProps = (dispatch: Dispatch<UserActions>) => ({
	signOutStart: () => dispatch(signOutStart())
});

const connector = connect(mapStateToProps, mapDispatchToProps);

type HeaderProps = ConnectedProps<typeof connector>;

export default connector(Header)

Typing mapStateToProps

Once your selectors have been imported into your Component you must select the slice of state, or slices of state that you need passed as a prop to your component. You pass them to mapStateToProps as follows:

//Imports
import { State } from '../../redux/root-reducer.types';

//Code
const mapStateToProps = (state: State) => ({
  currentUser: selectCurrentUser(state),
});

Here we use the State type which we got from our Root Reducer:

Additional information in Typing your Root Reducer

Typing mapDipsatchToProps

We need the Dispatch type from React, and Action Types for the actions we will be using:

//Imports
import React, { Dispatch } from 'react';
import { UserActions } from '../../redux/user/user.types';

//Code
const mapDispatchToProps = (dispatch: Dispatch<UserActions>) => ({
  signOutStart: () => dispatch(signOutStart()),
});

Dispatch needs the Actions it will be expecting to dispatch as the type in its generic.

Additional information in Typing Actions.

Connect and ConnectedProps

The part that varies the most in typing connect is that we need to break it into a two step process. We must extract the types first and then connect the Component. We must create a new variable containing a partial execution of connect, called connector by convention.

const connector = connect(mapStateToProps, mapDispatchToProps);

Once this is done we need to extract the types using ConnectedProps from react-redux.

//Imports
import { connect, ConnectedProps } from 'react-redux';

//Code
type HeaderProps = ConnectedProps<typeof connector>;

Our new type HeaderProps contains the props that we will pass to the component. Once we have this we use connector on our Header Component. The full code would be:

const connector = connect(mapStateToProps, mapDispatchToProps);

type HeaderProps = ConnectedProps<typeof connector>;

export default connector(Header);

Functional Component Props

Now that we have the type for the props, we just pass them to our Functional Component using React.FC:

const Header: React.FC<HeaderProps> = ({
	currentUser,
	signOutStart,
}) => (
	...
)

Congratulations! Now you have TS inference in your Functional Component.

Once we have all of this done we will have our Resulting Code.

Class Component Props

The react Class Component type needs two types in order to work: Props, and Internal State:

interface HeaderState {
	...
}

class Header extends Component<HeaderProps, HeaderState> {
	constructor(props: HeaderProps){
		super(props);
		this.state = {
			... //Something Matching HeaderState
		}
	}
	...
}

We get the props from our Redux HeaderProps and our Header State must match the interface we set for full support. If we aren't using any internal state, we can omit the second type in the generic.

Redux Type Setup: State, Root Reducer, Actions, and Selectors

Static typing can be like building a skyscraper: It is only as strong as its foundation. In the case of Redux the foundations are typing the Root Reducer, Actions, and Selectors.

Typing your Root Reducer

The first thing we need to do is get the type for our State, which is what our Root Reducer returns. My recommendation is to keep a separate *.types.ts file for any file you are typing to have a standardized file structure.

root-reducer.types.ts

import { rootReducer } from './root-reducer';

export type State = ReturnType<typeof rootReducer>;

This uses typescript's ReturnType to create a State type that updates as your Root Reducer grows and changes. This works by creating a type based on what our Root Reducer returns, which is our State. This approach will only work if you have correctly typed your reducers. TS Advanced Types DOCS for ReturnType

Typing Reducers

To type your Reducers, you will need two types, the type for your localState and your localActions. In the case of creating a Reducer for the slice of state holding Users we would do the following:

import { Reducer } from 'react';
import { UserActions, UserState, UserActionTypes } from './user.types';

const INTIAL_STATE: UserState = {
	...
}

const userReducer: Reducer<UserState, UserActions> = (
	state = INTIAL_STATE,
	action
) => {
	switch (action.type) {
		case UserActionTypes.SIGN_IN_SUCCESS:
			return {
				...
			}
		case ...
	}
};

We leverage the Reducer type from react, which needs two types in the generic: State, and Actions. Additionally, we have ActionTypes to get inference in our Switch Statement. With this setup, we the Root Reducer's type gets automatically updated when we add new reducers to it.

Typing Actions

In our userReducer we used types for our UserActions and UserActionTypes. The basic structure of an Redux Action is:

const ActionName = (payload: PayloadType) => ({
	type: string;
	payload: PayloadType;
})

Which returns an object with type and payload, which is our Action. For each action we have a predefined action "type" which we will type and use in our ActionObject interfaces. Redux Actions DOCS

ActionTypes

We create our types in user.types.ts using:

export const UserActionTypes = {
	SIGN_IN_SUCCESS: 'SIGN_IN_SUCCESS',
	SING_IN_FAILURE: 'SIGN_IN_FAILURE',
	...
} as const;

They key part is to use as const at the end. This will tell TS that the strings in our object will never change which will make it work and infer in our Switch Statement. TS Const Assertions DOCS

ActionObjects

For the objects that our actions will return, we will create interfaces:

interface SignInSuccessAction {
  type: typeof UserActionTypes.SIGN_IN_SUCCESS;
  payload: CurrentUser | null;
}

Here we used our hard-coded ActionTypes for the type property in our Action Object.

Once we have all of our ActionObjects typed we create a Discriminated Union to export all of our ActionObjects under a single type. TS Discriminated Union DOCS

export type UserActions =
	| SignInSuccessAction
	| SignInFailureAction
	| ...

We can stack as many actions as we want, and we can get type inference where we need to use actions just by using UserActions like we did in our Reducer.

Typing Selectors

We need a State type and a localState type to type Selectors. The localState is typed manually, in our case it is:

export interface UserState {
  currentUser: null | CurrentUser;
  error: null | string;
}

We get State from our root-reducer.types.ts file and use the Selector type from react-redux.

//Standard Imports
...
//Type Imports
import { Selector } from 'react-redux';
import { State } from '../root-reducer.types';
import { UserState } from '.user.types';

const selectUser: Selector<State, UserState> = (state) => state.user;

export const selectCurrentUser = createSelector(
	[selectUser],
	(user) => user.currentUser
);

Now when we use the selector in our Component and use mapStateToProps will infer the prop from the selector directly.

Once you have the setup completed, you can start Typing your Component using Redux connect.

Conclusion

Using Redux with TypeScript and React TSX in your application is a powerful tool that is easy to implement if you have your type foundations covered. Now you can get type inference for your Functional Components or Class Components with the use of connect. The key is using ConnectedProps from react-redux, Dispatch from react, and to use your own State, and Action types for mapStateToProps and mapDispatchToProps. To get the most off-hands and safest experience, type your Root Reducer, Actions, and Selectors to set up your type foundations.
